Patient monitor User’s manual
3
Masimo SpO
2
module
<0.3 136.6×102×40
A.4 Power Specifications
Input voltage 100V-240V AC
Frequency 50Hz/60Hz
Earth leakage current <0.3 mA
Input current
Q3/Q5:1.1A -0.5A
Q7:1.7A -0.8A
Standard requirement According to IEC 60601-1 and IEC 60601-1-2
Fuse T 2A/250V, integrated in the power module
A.5 Hardware Specifications
A.5.1 Display
Mainframe display
Type Color TFT LCD
Size（diagonal）
Q3: 10.4 inch
Q5: 12.1 inch,
Q7: 15 inch
Resolution
Q3/Q5: 800×600 pixels
Q7: 1024×768 pixels
External display
Type Medical-Grade TFT display
Size 15inch, 17inch, bigger size
Resolution Q3/Q5: 800×600 pixels
Q7: 1024×768 pixels
EMC MPR II, CISPR 11B
Third party certificate UL, C-UL, TUV, CE, FCC
A.5.2 Recorder
Model BTR50
Type Thermal dot array
