Patient monitor User’s manual
22-1
Chapter 22 Accessories
Warning:
Use only accessories specified in this manual. Using other accessories
may cause damage to the monitor.
Disposable accessories are designed for single-patient use only. Reuse
of them may cause a risk of contamination and affect the
measurement accuracy.
Check the accessories and their packages for any sign of damage. Do
not use them if any damage is detected.
1. ECG
ECG Cable
Type Description Standard PN
Snap 12-lead IEC 15-031-0001
Snap 5-lead IEC 15-031-0002
Snap 3-lead IEC 15-031-0013
Snap 12-lead AHA 15-031-0003
Snap 5-lead AHA 15-031-0004
Snap 3-lead AHA 15-031-0014
2. SpO
2
Nellcor SpO
2
sensor
Type Model Patient category
Disposable
MAX-A Adult finger (patient size>30kg)
MAX-P Pediatric foot/hand (patient size 10-50kg)
MAX-I Infant foot/hand (patient size 3-20kg)
MAX-N
Adult finger or neonatal foot/hand (patient
size >40 kg or <3 kg)
Reusable DS-100A Adult
