Patient Monitor User’s manual
3-9
 Changing Temp Label
1. Select【Module Set】smartkey to enter the Module config window in
which you can select the Temp label you want to alter. Then, there is a
module config window popping up.
2. Select 【Change Label】to rename the temp. Options are as follows:
Label Description Label Description
Tesoph Esophageal temperature Trect Rectal temperature
Tnaso Nasopharyngeal
temperature
Tblad Bladder temperature
Ttymp Tympanic temperature Tskin Skin temperature
T1 Non-specific temperature T2 Non-specific temperature
 Changing IBP Label
1. Select【Module Set】smartkey to enter the Module config window in which
you can select the IBP label you want to alter. Then, there is a module config
window popping up.
2. Select【Change Label】to rename the IBP. Options are as follows:
Label Description Label Description
ART Arterial blood pressure ICP Intracranial pressure
PA
Pulmonary artery pressure
RAP Right atrial pressure
CVP Central venous pressure LAP Left atrial pressure
P1 Non-specific pressure P2 Non-specific pressure
3.10.3 Resolving Label Conflicts
Each label must be unique, that is, it can only be assigned once. You
can’t monitor two pressures labeled “Tskin” at the same time. If you need to
use two identical temperatures, you must assign different labels to them.
Measurement labels are stored in the measurement module. If you try to use
two measurement modules with identical labels, the monitor will close the
second module automatically.
 IBP and Temp module
Take the Temp module for example, when your monitor has been equipped
with a Temp module (module A), and the module uses the label Tskin, then if
