Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory s e tting
UF5
SYn
UFq
nLd
[V/F 5pts]
(UF5): 5-segment V/F profile: As
[Standard]
(Std)
profile but also supports the avoidance of resonance
(saturation).
Voltage
UnS
U5
The profile is defined by the
U4
values of parameters UnS, FrS,
U0 to U5 and F1 to F5.
U3
U1
FrS > F5 > F4 > F3 > F2 > F1
U2
U0
Frequency
F1 F2 F3 F4 F5
FrS
Note:
U0 is the result of an internal calculation based on motor parameters and multiplied by UFr (%). U0 can be adjusted by
modifying UFr value.
[Sync. m ot.]
(SYn)
: For synchronous permanent magnet motors w ith sinusoidal electromotive force (EMF) only. This selection
makes the asynchronous motor parameters inaccessible, and the synchronous motor parameters accessible.
[V/F Quad.]
(UFq): Variable torque. For pump and fan applications.
[Ene rgy Sav.]
(nLd): Energy saving. For applications that do not require high dynamics.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > DRC- > ASY-
