Configuration Mode (ConF)
Asynchronous motor parameters: Expert mode
Code Nam e / De s cription Adjustment range Factory s e tting
rSA
*
(1)
[Cust stator resist.]
0 to 65,535 mOhm 0 mOhm
Cold state stator resistance (per winding), modifiable value.
The factory setting is replaced by the result of the auto-tuning operation, if it has been performed.
LFA
*
[Lfw]
0 to 655.35 mH 0 mH
Cold state leakage inductance, modifiable value.
The factory setting is replaced by the result of the auto-tuning operation, if it has been performed.
IdA
*
[Idw]
0 to 6,553.5 A 0 A
Customer adjusted magnetizing current.
The factory setting is replaced by the result of the auto-tuning operation, if it has been performed.
tr
A
*
[Cust. rotor t const.]
0 to 65,535 ms 0 ms
Customer adjusted rotor time constant.
The factory setting is replaced by the result of the auto-tuning operation, if it has been performed.
(1) On the integrated display unit: 0 to 9,999 then 10.00 to 65.53 (10,000 to 65,535).
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > DRC- > ASY-
*
