Configuration Mode (ConF)
193
Brake logic control, vertical movement in open-loop mode
Frequenc y
Reference
bIr
JdC
JdC
bEn
Flux current
Rated flux
current
Torque current
Ibr
Direction of
operation
Relay
or logic
output
0
Brake contact
State of brake
Released
Engaged
Type of motor
control
Key:
• (bEn): [Brake engage freq]
• (bEt): [Brake engage time]
• (bIr) : [Brake release fr eq]
• (brt): [Brake Release time]
• (Ibr): [Brake release I FW ]
• (JdC): [Jump at reversal]
• (tbE): [Brake engage delay]
• (ttr): [Time to restart]
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FUN- > BLC-
Fluxed motor
Ibr attained
Ascending Descending
tbE bEt ttr
0 attained
brt
Flux
Torque
I
n
j
ec
ti
on
Locking
