Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
Note:
This function cannot be used w ith certain other functions. Follow the instructions on page 163.
HSO
nO
SSO
CSO
[High speed hoisting]
[No]
(nO)
[No]
(nO): Function inactive
[Spe e d ref]
(SSO): Speed reference mode
[I Lim it]
(CSO): Current limitation mode
COF
*
[Motor speed coeff.]
0 to 100% 100%
Speed reduction coefficient calculated by the drive for Ascending direction.
This parameter can be accessed if
[High s peed hoisting]
(HSO) is set to
[Spe e d ref]
(SSO).
CO
r
*
[Gen. speed coeff]
0 to 100% 50%
Speed reduction coefficient calculated by the drive for Descending direction.
This parameter can be accessed if
[High s peed hoisting]
(HSO) is not set to
[No]
(nO).
tOS
*
[Load measuring tm.]
0.1 s to 65 s 0.5 s
Duration of speed step for measurement.
This parameter can be accessed if
[High s peed hoisting]
(HSO) is not set to
[No]
(nO).
OSP
*
[Measurement spd]
0 to
[Rated m otor freq.]
(FrS)
40 Hz
Speed stabilized for measurement.
This parameter can be accessed if
[High s peed hoisting]
(HSO) is not set to
[No]
(nO).
CLO
*
[High speed I Limit]
0 to 1.5 In (1) In (1)
Current limitation at high speed.
This parameter can be accessed if
[High s peed hoisting]
(HSO) is set to
[I Lim it]
(CSO).
Note:
If the setting is less than 0.25 In, the drive may lock in
[Output Phas e Loss]
(OPL) fault mode if this has been enabled
(see page 256).
SCL
*
[I Limit. frequency]
0 to 599 Hz according to rating 40 Hz
Frequency threshold, above w hich the high-speed limitation current is active.
This parameter can be accessed if
[High s peed hoisting]
(HSO) is set to
[I Lim it]
(CSO).
rSd
*
nO
drI
PES
[Rope slack config.]
[No]
(nO)
Rope slack function.
This parameter can be accessed if
[High s peed hoisting]
(HSO) is not set to
[No]
(nO).
[No]
(nO): Function inactive
[Driv e
estim.]
(
drI
):
Measure m ent
of
the
load
by
estimating
the
torque
generat e d
by
the
drive
[Ext. s e nsor]
(PES): Measurement of the load using a w eight sensor, can only be assigned if
[Weight sensor as s.]
(PES)
page 200 is not
[No]
(nO)
rStL
*
[Rope slack trq level]
0 to 100% 0%
Adjustment threshold corresponding to a load w eighing slightly less than the hook w hen off-load, as a % of the rated load.
This parameter can be accessed if
[Rope slack trq level]
(rSd)
has been assigned.
(1) In corresponds to the rated drive current indicated in the Installation manual and on the drive nameplate.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
*
