Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
Note
: This function cannot be used w ith certain other functions. Follow the instructions on page 163.
PIF
nO
A11
A12
A13
OA01
...
OA10
[PID feedback ass.]
[No]
(nO)
[No]
(nO): Not assigned
[Al1]
(A11): Analog input A1
[Al2]
(A12): Analog input A2
[Al3]
(A13): Analog input A3
[RP]
(PI): Pulse input
[AI virtual 1]
(AIU1): Virtual analog input 1 by the communication bus
[AI virtual 2]
(AIU2): Virtual analog input 2 by the communication bus
[OA01]
(OA01): Function blocks: Analog Output 01
...
[OA10]
(OA10): Function blocks: Analog Output 10
AIC2
*
nO
Mdb
CAn
nEt
[AI2 net. channel]
[No]
(
nO
)
This parameter can be accessed if
[PID fe e dback as s.]
(PIF)
is set to
[AI virtual 2]
(AIU2).
This parameter can also be
accessed in the
[INPUTS / OUTPUTS CFG]
(
I_O
-
)
menu.
[No]
(nO): Not assigned
[M odbus ]
(Mdb): Integrated Modbus
[CANope n]
(CAn): Integrated CANopen®
[Com . card]
(nEt): Communication card (if inserted)
PIF1
*
(1)
[Min PID feedback]
0 to
[M ax PID feedback ]
(PIF2)
(2)
100
Value for minimum feedback.
PIF2
*
(1)
[Max PID feedback]
[M in PID fe e dback]
(PIF1)
1,000
Value for maximum feedback.
PIP1
*
(1)
[Min PID reference]
[M in PID feedback ]
(PIF1)
to
[M ax PID re fe rence ]
(PIP2)
(2)
150
Minimum process value.
PIP2
*
(1)
[Max PID reference]
[M in PID refe rence]
(PIP1)
to
[M ax PID fe e dback]
(PIF2)
(2)
900
Maximum process value.
PII
*
nO
YES
[Act. internal PID ref.]
[No]
(
nO
)
Internal PID regulator reference.
[No]
(nO): The PID regulator reference is given by
[Ref.1 channel]
(Fr1)
or
[Ref.1B channe l]
(Fr1b)
with
summing/subtraction/multiplication functions (see the diagram on page 206).
[Yes]
(
YES
):
The
PID
regulator
reference
is
internal
via
[Intern al
PID
ref.]
(
rPI
).
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FUN- > PID-
