Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
Note:
This function cannot be used w ith certain other functions. Follow the instructions on page 163.
SAF
nO
LI1
...
[Stop FW limit sw.]
[No]
(nO)
Stop sw itch forw ard.
[No]
(nO): Not assigned
[LI1]
(LI1):
Logical input LI1
[...]
(...): See the assignment conditions on page 153
SA
r
[Stop RV limit sw.]
[No]
(nO)
Stop sw itch reverse.
Identical to
[Stop FW lim it s w .]
(SAF) above.
SAL
*
LO
HIG
[Stop limit config.]
[Active low ]
(LO)
WARNING
LOSS OF CONTROL
If
[Stop limit config.]
(SAL) is s et to
[Active high]
(HIG), the stop com mand will be activated on active
signal and the stop com m and will not be applied if the connection is rem oved.
Verify that us ing this s etting does not res ult in uns afe conditions.
Failure to follow these instructions can result in death, serious injury, or equipment damage.
Stop sw itch activation level.
This parameter can be accessed if at least one limit sw itch or one stop sensor has been assigned. It defines the positive or
negative logic of the bits or inputs assigned to the stop.
[Active low]
(LO): Stop controlled on a falling edge (change from 1 to 0) of the assigned bits or inputs
[Active high]
(HIG): Stop controlled on a rising edge (change from 0 to 1) of the assigned bits or inputs
dAF
[Slowdown forward]
[No]
(nO)
Slow down attained forward.
Identical to
[Stop FW lim it s w .]
(SAF) above.
dAr
[Slowdown reverse]
[No]
(nO)
Slow down attained reverse.
Identical to
[Stop FW lim it s w .]
(SAF) above.
dAL
*
LO
HIG
[Slowdown limit cfg.]
[Active low ]
(LO)
WARNING
LOSS OF CONTROL
If
[Slowdown limit cfg.]
(dAL) is set to
[Active high]
(HIG), the slowdown com m and will be activated on
active signal and the s lowdown com m and will not be applied if the connection is rem oved.
Verify that us ing this s etting does not res ult in uns afe conditions.
Failure to follow these instructions can result in death, serious injury, or equipment damage.
This parameter can be accessed if at least one limit sw itch or one slowdown sensor has been assigned. It defines the positive
or negative logic of the bits or inputs assigned to the slow down.
[Active low]
(LO): Slowdown controlled on a falling edge (change from 1 to 0) of the assigned bits or inputs
[Active high]
(HIG): Slow dow n controlled on a rising edge (change from 0 to 1) of the assigned bits or inputs
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FUN- > LPO-
