Configuration Mode (ConF)
Configuration information output
In the
[INPUTS / OUTPUTS
C
FG]
(I_O-
) m enu, a logic output can be ass igned to each configuration or
m otor (2 or 3) for rem ote inform ation transm ission.
Note:
As the
[INPUTS
/ OUTPUTS CFG]
(
I_O-
) m enu is switched, thes e outputs m ust be as signed in all
configurations in which inform ation is required.
Code Nam e / De s cription Adjustment range Factory setting
CHM
nO
YES
[Multimotors]
[No]
(nO)
NOTICE
MOTOR OVERHEATING
When the drive is s witched off, the therm al s tates of the connected m otors are not saved.
When the drive is s witched on again, the drive is not aware of the therm al s tates of the connected m otors.
•
Us e separate tem perature sensors for each connected m otor for therm al m onitoring.
Failure to follow these instructions can result in equipment damage.
[No]
(nO): Multiconfiguration possible
[Ye s ]
(YES): Multimotor possible
CnF1
nO
LI1
...
[2 Configurations]
[No]
(nO)
Sw itching of 2 motors or 2 configurations.
[No]
(nO): No sw itching
[LI1]
(LI1):
Logical input LI1
[...]
(...): See the assignment conditions on page 153
CnF2
[3 Configurations]
[No]
(nO)
Sw itching of 3 motors or 3 configurations.
Identical to
[2 Configurations ]
(CnF1) page 235.
Note:
In order to obtain 3 motors or 3 configurations,
[2 Configurations ]
(CnF1) must also be configured.
