Configuration Mode (ConF)
Counter wobble
Master drive Slave drive
Synchron iz at ion
Gearbox
Reel of yarn
Main shaft
Winding motor
Thread guide
Thread
The Counter wobble function is us ed in certain applications to obtain a cons tant yarn tension when the
Travers e control function is producing cons iderable variations in speed on the yarn guide m otor
(
[T
raverse
f
re
q. high
]
(
trH
) and
[T
raverse
F
r
eq. low
]
(
tr
L
), see
[T
raverse
freq. high]
(
tr
H
) page
242).
Two m otors m ust be us ed (one m aster and one slave).
The m as ter controls the s peed of the yarn guide, the s lave controls the winding s peed. The function as signs
the s lave a s peed profile, which is in antiphas e to that of the m as ter. This m eans that s ynchronization is
required, us ing one of the m as ter’s logic outputs and one of the slave’s logic inputs.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > FUN- > TRO-
