Configuration Mode (ConF)
Code Nam e / De s cription Adjus tment range Factory s e tting
SnC
*
nO
LI1
...
[Counter wobble]
[No]
(nO)
Synchronization input.
To be configured on the w inding drive (slave) only.
[No]
(nO): Function inactive, thereby helping to prevent access to other parameters
[LI1]
(LI1):
Logical input LI1
[...]
(...): See the assignment conditions on page 153
tSY
*
nO
LO1
r2
dO1
[Sync. wobble]
[No]
(nO)
Synchronization output.
To be configured on the yarn guide drive (master) only.
[No]
(nO): Function not assigned
[LO1]
(LO1)
[R2]
(r2)
[dO1]
(dO1): Analog output AO1 functioning as a logic output. Selection can be made if
[AO1 assignment]
(AO1) page 144
is set to
[No]
(nO).
dtF
*
[Decrease ref. speed]
0 to 599 Hz 0 Hz
Decrease in the base reference during the traverse control cycle.
rtr
*
nO
LI1
...
[Init. traverse ctrl]
[No]
(nO)
When the state of the assigned input or bit changes to 1, the traverse control operating time is reset to 0, along w ith
[Decreas e ref. s peed]
(dtF).
[No]
(nO): Function not assigned
[LI1]
(LI1):
Logical input LI1
[...]
(...): See the assignment conditions on page 153
(1) The parameter can also be accessed in the
[SETTINGS]
(SEt-)
menu.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
*
