Configuration Mode (ConF)
HIGH SPEED SWITCHING
Code Nam e / De s cription Adjustment range Factory setting
SH2
nO
F2A
LI1
...
[2 High speed]
[No]
(nO)
High Speed Sw itching.
[No]
(nO): Function not assigned
[Freq. Th. attain.]
(FtA):
Frequency threshold attained
[Freq. Th. 2 attaine d]
(F2A): Frequency threshold 2 attained
[LI1]
(LI1):
Logical input LI1
[...]
(...): See the assignment conditions on page 153
SH4
[4 High speed]
[No]
(nO)
High Speed Sw itching.
Note:
In order to obtain 4 High speed,
[2 High s pe ed]
(SH2) must also be configured.
Identical to
[2 High s pe ed]
(SH2) page 244.
HSP
[High speed]
0 to 599 Hz 50 Hz
Motor
frequency
at
maximum
reference,
can
be
set
between
[Low
spee d]
(
LS
P
)
and
[Max
freque n c y]
(
tFr
).
The factory setting changes to 60 Hz if
[Standard m ot. freq]
(bFr)
is set to
[60Hz NEM A]
( 0).
HSP2
*
[High speed 2]
0 to 599 Hz 50 Hz
Visible if
[2 High s pe ed]
(SH2) is not set to
[No]
(nO).
Identical to
[High s pe ed]
(HSP) page 244.
HSP3
*
[High speed 3]
0 to 599 Hz 50 Hz
Visible if
[4 High s pe ed]
(SH4) is not set to
[No]
(nO).
Identical to
[High s pe ed]
(HSP) page 244.
HSP4
*
[High speed 4]
0 to 599 Hz 50 Hz
Visible if
[4 High s pe ed]
(SH4) is not set to
[No]
(nO).
Identical to
[High s pe ed]
(HSP) page 244.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL>CHS-
*
