Communication map configuration
Code Nam e / De s cription Factory setting
IAd1
[Word 1 add. select.]
0
Select the address of the w ord to be displayed by pressing the << and >> (F2 and F3) keys and rotating the jog dial.
FAd1
HE
SIG
nSG
[Format word 1]
[Hex]
(HE )
Format of w ord 1.
[Hex]
(HE )
[Signe d]
(SIG)
[Unsigne d]
(nSG)
IAd2
[Word 2 add. select.]
0
Select the address of the w ord to be displayed by pressing the << and >> (F2 and F3) keys and rotating the jog dial.
FAd2
HE
SIG
nSG
[Format word 2]
[Hex]
(HE )
Format of w ord 2.
[Hex]
(HE )
[Signe d]
(SIG)
[Unsigne d]
(nSG)
IAd3
[Word 3 add. select.]
0
Select the address of the w ord to be displayed by pressing the << and >> (F2 and F3) keys and rotating the jog dial.
FAd3
HE
SIG
nSG
[Format word 3]
[Hex]
(HE )
Format of w ord 3.
[Hex]
(HE )
[Signe d]
(SIG)
[Unsigne d]
(nSG)
IAd4
[Word 4 add. select.]
0
Select the address of the w ord to be displayed by pressing the << and >> (F2 and F3) keys and rotating the jog dial.
FAd4
HE
SIG
nSG
[Format word 4]
[Hex]
(HE )
Format of w ord 4.
[Hex]
(HE )
[Signe d]
(SIG)
[Unsigne d]
(nSG)
Then, it w ill be possible to view the selected w ords in the
[COM M UNICATION M AP]
submenu of the
[1.2 MONITORING]
menu.
Example:
Parameter that can be modified during operation or w hen stopped.
Parameters described in this page can be accessed by:
ITF- > MCF- > ADL-/DCF-
- - - - -- - - - -
W3141: F230 Hex
