Code Nam e / De s cription Unit
Bit 10: Reference reached
= 0: The reference is not reached
= 1: The reference has been reached
Bit 11: Reference outside limits
= 0: The reference is w ithin the limits
= 1: The reference is not w ithin the limits
When the drive is in speed mode, the limits are defined by LSP and HSP parameters.
Bit 12 and Bit 13: Reserved (= 0)
Bit 14: Stop via STOP key
= 0: STOP key not pressed
= 1: Stop triggered by the STOP key on the graphic display terminal or the remote display terminal
Bit 15: Direction of rotation
= 0: Forw ard rotation at output
= 1: Reverse rotation at output
Modbus netw ork diagnostic.
Mdb1
[COM LED]
View of the Modbus Communication.
M1C
t
[Mb NET frames nb.]
Modbus netw ork frame counter: Number of processed frames.
M1EC
[Mb NET CRC errors]
Modbus netw ork CRC error counter: Number of CRC errors.
Used for CANopenĀ® and Modbus Netw ork.
nM1
[Com Scan In1 val.]
Value of the 1st input w ord.
nM2
[Com Scan In2 val.]
Value of the 2nd input w ord.
nM3
[Com Scan In3 val.]
Value of the 3rd input w ord.
nM4
[Com Scan In4 val.]
Value of the 4th input w ord.
nM5
[Com Scan In5 val.]
Value of the 5th input w ord.
nM
[Com Scan In6 val.]
Value of the 6th input w ord.
nM7
[Com Scan In7 val.]
Value of the 7th input w ord.
nM8
[Com Scan In8 val.]
Value of the 8th input w ord.
nC1
[Com Scan Out1 val.]
Value of the 1st output w ord.
nC2
[Com Scan Out2 val.]
Value of the 2nd output w ord.
nC3
[Com Scan Out3 val.]
Value of the 3rd output w ord.
nC4
[Com Scan Out4 val.]
Value of the 4th output w ord.
nC5
[Com Scan Out5 val.]
Value of the 5th output w ord.
Parameters described in this page can be accessed by:
DRI- > MON- > CMM-
