Monitoring Mode (MOn)
59
Code Nam e / De s cription Unit
nC6
[Com Scan Out6 val.]
Value of the 6th output w ord.
nC7 [Com Scan Out7 val.]
Value of the 7th output w ord.
nC8 [Com Scan Out8 val.]
Value of the 8th output w ord.
CMM
-
[COMMUNICATION MAP]
(continued)
C
I
-
[CMD. WORD IMAGE]
Command w ord image: Only accessible via graphic display terminal.
CMd1 [Modbus cmd.]
Modbus command w ord image.
CMd2 [CANopen cmd.]
CANopen® command w ord image.
CMd3 [COM. card cmd.]
Communication card command w ord image.
CMM
-
[COMMUNICATION MAP]
(continued)
r
I
-
[FREQ. REF. WORD MAP]
Frequency reference image: Only accessible via graphic display terminal.
LFr1 [Modbus ref.]
Hz
Modbus frequency reference image.
LFr2 [CANopen ref.]
Hz
CANopen® frequency reference image.
LFr3 [Com. card ref.]
Hz
Communication card frequency reference image.
CMM
-
[COMMUNICATION MAP]
(continued)
CnM
-
[CANopen MAP]
CANopen® image: Only accessible via graphic display terminal.
COn [RUN LED]
View of the CANopen® RUN Led Status.
CAnE [ERR LED]
View of the CANopen® Error Led Status.
PO
1
-
[PDO1 IMAGE]
View of the RPDO1 and TPDO1.
rp11
*
[Received PDO1-1]
First frame of the received PDO1.
rp12
*
[Received PDO1-2]
Second frame of the received PDO1.
rp13
*
[Received PDO1-3]
Third frame of the received PDO1.
rp14
*
[Received PDO1-4]
Fourth frame of the received PDO1.
tp11
*
[Transmit PDO1-1]
First frame of the transmit PDO1.
Parameters described in this page can be accessed by:
DRI- > MON- > CMM- > OSA-
