Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range
Factory setting
tFr
[Max frequency]
10 to 599 Hz 60 Hz
The factory setting is 60 Hz, or preset to 72 Hz if
[Standard m ot. freq]
(bFr)
is set to 60 Hz.
The maximum value is limited by the follow ing conditions:
It must not exceed 10 times the value of
[Rated m otor freq.]
(FrS).
See
[Max
freque nc y ]
(
tFr
)
page
105.
tUn
[Auto tuning]
[No action]
(nO)
For asynchronous motors, see page 108.
For synchronous motors, see page 113.
tUS
tAb
PEnd
PrOG
FAIL
dOnE
[Auto tuning state]
[Not done ]
(tAb)
This parameter is not saved at drive pow er off. It show s the Autotuning status since last power on.
See
[Auto tuning s tate]
(tUS)
page 108.
[Not done ]
(tAb):
Autotune is not done
[Pe nding]
(PEnd): Autotune has been requested but not yet performed
[In Progress]
(PrOG): Autotune is in progress
[Faile d]
(FAIL):
Autotune has detected a fault
[Done ]
(dOnE): The stator resistance measured by the auto-tuning function is used to control the motor
StUn
MEAS
CUS
[Tune selection]
[Default]
(tAb)
See
[Tune s e le ction]
(StUn)
page 108.
[Default]
(tAb):
The default stator resistance value is used to control the motor
[M e asure]
(MEAS): The stator resistance measured by the auto-tuning function is used to control the motor
[Cus tom]
(CUS): The stator resistance set manually is used to control the motor
ItH
[Mot. therm. current]
0.2 to 1.5 In (1) According to drive rating
Motor thermal protection current, to be set to the rated current indicated on the motor nameplate.
See
[Mot.
therm.
curre nt ]
(
ItH
)
page
90.
ACC
[Acceleration]
0.00 to 6,000 s (2) 3.0 s
Time to accelerate from 0 to the
[Rated m otor freq.]
(FrS)
(page 86). To have repeatability in ramps, the value of this
parameter must be set according to the possibility of the application.
See
[Accele ration]
(ACC) page 89.
dEC
[Deceleration]
0.00 to 6,000 s (2) 3.0 s
Time to decelerate from the
[Rated m otor freq.]
(FrS)
(page 86) to 0. To have repeatability in ramps, the value of this
parameter must be set according to the possibility of the application.
See
[Dece leration]
(dEC) page 89.
LSP
[Low speed]
0 to 599 Hz
0
Motor frequency at minimum reference, can be set betw een 0 and
[High s pe e d]
(HSP).
See
[Low spe e d]
(LSP) page 89.
HSP
[High speed]
0 to 599 Hz 50 Hz
Motor
frequency
at
maximum
reference,
can
be
set
between
[Low
spee d]
(
LS
P
)
and
[Max
freque n c y]
(
tFr
).
The
factory
setting changes to 60 Hz if
[Standard m ot. freq]
(bFr)
is set to
[60Hz NEM A]
( 0).
See
[High spe e d]
(HSP) page 89.
(1)
In corresponds to the rated drive current indicated in the Installation manual and on the drive nameplate.
(2)
Range 0.01 to 99.99 s or 0.1 to 999.9 s or 1 to 6,000 s according to
[Ra mp
incre m e nt]
(
Inr
)
page
170.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
To change the assignment of this parameter, press the ENT key for 2 s.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > SIM-
