Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
Inr
0.01
0.1
1
[Ramp increment]
0.1
This parameter is valid for
[Accele ration]
(ACC),
[Dece leration]
(dEC),
[Accele ration 2]
(AC2) and
[Decele ra tio n
2]
(
dE2
).
See
[Ra mp
incre m e nt]
(
Inr
)
page
170.
[0,01]
: Ramp up to 99.99 seconds
[0,1]
: Ramp up to 999.9 seconds
[1]
: Ramp up to 6,000 seconds
ACC
[Acceleration]
0.00 to 6,000 s (1) 3.0 s
Time to accelerate from 0 to the
[Rated motor freq.]
(FrS)
page 86. To have repeatability in ramps, the value of this parameter
must be set according to the possibility of the application. See
[Accele ration]
(ACC) page 170.
dEC
[Deceleration]
0.00 to 6,000 s (1) 3.0 s
Time to decelerate from the
[Rated motor freq.]
(FrS)
page 86 to 0. To have repeatability in ramps, the value of this parameter
must be set according to the possibility of the application. See
[Dece leration]
(dEC) page 170.
AC2
*
[Acceleration 2]
0.00 to 6,000 s (1) 5 s
Time to accelerate from 0 to the
[Rated motor freq.]
(FrS)
page 86. To have repeatability in ramps, the value of this parameter
must be set according to the possibility of the application. See
[Accele ration 2]
(AC2) page 171.
dE2
*
[Deceleration 2]
0.00 to 6,000 s (1) 5 s
Time to decelerate from the
[Rated motor freq.]
(FrS)
page 86 to 0. To have repeatability in ramps, the value of this parameter
must be set according to the possibility of the application. See
[Dece leration 2]
(dE2)
page 171.
tA1
*
[Begin Acc round]
0 to 100% 10%
Rounding of start of acceleration ramp as a % of the
[Accele ration]
(ACC) or
[Acceleration 2]
(AC2) ramp time. Visible if
[Ramp
type]
(
rP
t
)
is
set
to
[Cust om iz e d]
(
CUS
).
See
[Begin
Acc
round ]
(
tA1
)
page
170.
tA2
*
[End Acc round]
0 to 100% 10%
Rounding of end of acceleration ramp as a % of the
[Accele ration]
(ACC) or
[Acceleration 2]
(AC2) ramp time.
Can be set betw een 0 and 100% -
[Begin Acc round]
(tA1).
Visible
if
[Ra mp
type]
(
rPt
)
is
set
to
[Cust om ize d]
(
CUS
).
See
[End
Acc
round ]
(
tA2
)
page
171.
tA3
*
[Begin Dec round]
0 to 100% 10%
Rounding of start of deceleration ramp as a % of the
[Dece leration]
(dEC) or
[Dece leration 2]
(dE2) ramp time. Visible if
[Ramp
type]
(
rP
t
)
is
set
to
[Cust om iz e d]
(
CUS
).
See
[Begin
Dec
round ]
(
tA3
)
page
171.
tA4
*
[End Dec round]
0 to 100% 10%
Rounding of end of deceleration ramp as a % of the
[Dece leration]
(dEC) or
[Dece leration 2]
(dE2) ramp time.
Can be set betw een 0 and 100% -
[Begin De c round]
(tA3).
Visible
if
[Ra mp
type]
(
rPt
)
is
set
to
[Cust om ize d]
(
CUS
).
See
[End
Dec
round ]
(
tA4
)
page
171.
LSP
[Low speed]
0 to 599 Hz 0 Hz
Motor frequency at minimum reference, can be set betw een 0 and
[High speed]
(HSP) page 87. See
[Low spe ed]
(LSP)
page 87.
HSP
[High speed]
0 to 599 Hz 50 Hz
Motor
frequency
at
maximum
reference,
can
be
set
between
[Low
spee d]
(
LSP
)
and
[Max
freque n c y]
(
tF
r
).
The
factory
setting changes to 60 Hz if
[Standard m ot. freq]
(bFr)
is set to
[60Hz NEM A]
( 0). See
[High speed]
(HSP) page 87.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > SET-
