Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
HSP2
*
[High speed 2]
0 to 599 Hz 50 Hz
Visible if
[2 High s pe e d]
(SH2) is not set to
[No]
(nO). See
[High spe e d 2]
(HSP2) page 244.
HSP3
*
[High speed 3]
0 to 599 Hz 50 Hz
Visible if
[4 High s pe e d]
(SH4) is not set to
[No]
(nO). See
[High spe e d 3]
(HSP3) page 244.
HSP4
*
[High speed 4]
0 to 599 Hz 50 Hz
Visible if
[4 High s pe e d]
(SH4) is not set to
[No]
(nO). See
[High spe e d 4]
(HSP4) page 244.
It
H
[Mot. therm. current]
0.2 to 1.5 In (2) According to drive rating
Motor thermal protection current, to be set to the rated current indicated on the motor nameplate.
See
[Mot.
therm.
curre n t]
(
ItH
)page
87.
UF
r
[IR compensation]
0 to 200% 100%
IR compensation. See
[IR com pre nsation]
(UFr) page 118.
SLP
*
[Slip compensation]
0 to 300% 100%
Slip compensation. See
[Slip com pe nsation]
(SLP) page 118.
SFC
*
[K speed loop filter]
0 to 100 65
Speed filter coefficient. See
[K spe ed loop filter]
(SFC) page 118.
SIt
*
[Speed time integral]
1 to 65,535 ms 63 ms
Speed
loop
integral
time
constant.
See
[Spee d
time
integ ra l]
(
SIt
)
page
118.
SPG
*
[Speed prop. gain]
0 to 1,000% 40%
Speed loop proportional gain. See
[Spe e d prop. gain]
(SPG) page 118.
SPGU
*
[UF inertia comp.]
0 to 1,000% 40%
Inertia factor. See
[UF ine rtia comp.]
(SPGU) page 118.
(1) Range
0.01
to
99.99
s
or
0.1
to
999.9
s
or
1
to
6,000
s
according
to
[Ra mp
incre m e nt ]
(
In
r
)
page
170.
(2)
In corresponds to the rated drive current indicated in the Installation manual or on the drive nameplate.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > SET-
*
