Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
dCF
*
[Ramp divider]
0 to 10
4
Deceleration ramp time reduction. See
[Ram p divide r]
(dCF) page 173.
IdC
*
[DC inject. level 1]
0.1 to 1.41 In (1) 0.64 In (1)
Level of DC injection braking current activated via logic input or selected as stop mode. See
[DC inject. le vel 1]
(IdC)
page
174.
tdI
*
[DC injection time 1]
0.1 to 30 s 0.5 s
Maximum current injection time
[DC inject. le vel 1]
(IdC).
After this time, the injection current becomes
[DC inje ct. le vel 2]
(IdC2).
See
[DC inje ction tim e 1]
(td1)
page 174.
IdC2
*
[DC inject. level 2]
0.1 In to 1.41 In (1) 0.5 In (1)
Injection
current
activated
by
logic
input
or
selected
as
stop
mode,
once
period
of
time
[DC
injec tio n
time
1]
(
tdI
)
has
elapsed.
See
[DC inje ct. le vel 2]
(IdC2)
page 175.
tdC
*
[DC injection time 2]
0.1 to 30 s 0.5 s
Maximum injection time
[DC inject. le vel 2]
(IdC2)
for injection selected as stop mode only.
See
[DC injection tim e 2]
(tdC)
page 175.
SdC1
*
[Auto DC inj. level 1]
0 to 1.2 In (1) 0.7 In (1)
NOTICE
OVERHEATING AND DAMAGE TO THE MOTOR
Verify that the connected m otor is properly rated for the DC injection current to be applied in term s of am ount
and tim e in order to avoid overheating and dam age to the motor.
Failure to follow these instructions can result in equipment damage.
Level of standstill DC injection current
[Auto DC inje ction]
(AdC) is not
[No]
(nO).
See page 176.
tdC1
*
[Auto DC inj. time 1]
0.1 to 30 s 0.5 s
NOTICE
OVERHEATING AND DAMAGE TO THE MOTOR
Verify that the connected m otor is properly rated for the DC injection current to be applied in term s of am ount
and tim e in order to avoid overheating and dam age to the motor.
Failure to follow these instructions can result in equipment damage.
Standstill injection time. This parameter can be accessed if
[Auto DC inje ction]
(AdC) is not set to
[No]
(nO).
If
[Mot o r
control
type]
(
Ctt
)
page
105
is
set
to
[Sync .
mot.]
(
SYn
),
this
time
correspo nds
to
the
zero
speed
maintena nc e
time.
See page 176.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > SET-
