BL702/704/706 Reference Manual
4.4.8 gpadc_reg_scn_neg1
Address：0x4000f920
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD SCN5 SCN4 SCN3
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SCN3 SCN2 SCN1 SCN0
Bits
Name Type Reset Description
31:30 RSVD
29:25 SCN5 R/W 5’hf definition is the same as adc_reg_cmd.adc_neg_sel
24:20 SCN4 R/W 5’hf definition is the same as adc_reg_cmd.adc_neg_sel
19:15 SCN3 R/W 5’hf definition is the same as adc_reg_cmd.adc_neg_sel
14:10 SCN2 R/W 5’hf definition is the same as adc_reg_cmd.adc_neg_sel
9:5 SCN1 R/W 5’hf definition is the same as adc_reg_cmd.adc_neg_sel
4:0 SCN0 R/W 5’hf definition is the same as adc_reg_cmd.adc_neg_sel
4.4.9 gpadc_reg_scn_neg2
Address：0x4000f924
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD SCN11 SCN10 SCN9
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SCN9 SCN8 SCN7 SCN6
Bits
Name Type Reset Description
31:30 RSVD
29:25 SCN11 R/W 5’hf definition is the same as adc_reg_cmd.adc_neg_sel
24:20 SCN10 R/W 5’hf definition is the same as adc_reg_cmd.adc_neg_sel
19:15 SCN9 R/W 5’hf definition is the same as adc_reg_cmd.adc_neg_sel
14:10 SCN8 R/W 5’hf definition is the same as adc_reg_cmd.adc_neg_sel
9:5 SCN7 R/W 5’hf definition is the same as adc_reg_cmd.adc_neg_sel
4:0 SCN6 R/W 5’hf definition is the same as adc_reg_cmd.adc_neg_sel
