BL702/704/706 Reference Manual
4.4.10 gpadc_reg_status
Address：0x4000f928
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD DARD
Bits
Name Type Reset Description
31:1 RSVD
0 DARD R 1’b0 ADC final conversion data ready
4.4.11 gpadc_reg_isr
Address：0x4000f92c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD PSM NSM RSVD PSC NSC RSVD PS NS
Bits
Name Type Reset Description
31:10 RSVD
9 PSM R/W 1’h0 write 1 mask
8 NSM R/W 1’h0 write 1 mask
7:6 RSVD
5 PSC R/W 1’b0 Write 1 to clear flag
4 NSC R/W 1’b0 Write 1 to clear flag
3:2 RSVD
1 PS R 1’b0 ADC data positive side saturation interrupt flag
0 NS R 1’b0 ADC data negative side saturation interrupt flag
