BL702/704/706 Reference Manual
8.4.10 irtx_swm_pw_3
Address：0x4000a64c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TXSWPW3
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TXSWPW3
Bits
Name Type Reset Description
31:0 TXSWPW3 R/W 32’h0 IRTX Software Mode pulse width data #24 #31, each pulse
is represented by 4-bit
([3:0] is the 1st pulse, [7:4] is the 2nd pulse, [11:8] is the 3rd
pulse, etc)
8.4.11 irtx_swm_pw_4
Address：0x4000a650
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TXSWPW4
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TXSWPW4
Bits
Name Type Reset Description
31:0 TXSWPW4 R/W 32’h0 IRTX Software Mode pulse width data #32 #39, each pulse
is represented by 4-bit
([3:0] is the 1st pulse, [7:4] is the 2nd pulse, [11:8] is the 3rd
pulse, etc)
8.4.12 irtx_swm_pw_5
Address：0x4000a654
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TXSWPW5
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TXSWPW5
