BL702/704/706 Reference Manual
Bits
Name Type Reset Description
31:0 TXSWPW5 R/W 32’h0 IRTX Software Mode pulse width data #40 #47, each pulse
is represented by 4-bit
([3:0] is the 1st pulse, [7:4] is the 2nd pulse, [11:8] is the 3rd
pulse, etc)
8.4.13 irtx_swm_pw_6
Address：0x4000a658
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TXSWPW6
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TXSWPW6
Bits
Name Type Reset Description
31:0 TXSWPW6 R/W 32’h0 IRTX Software Mode pulse width data #48 #55, each pulse
is represented by 4-bit
([3:0] is the 1st pulse, [7:4] is the 2nd pulse, [11:8] is the 3rd
pulse, etc)
8.4.14 irtx_swm_pw_7
Address：0x4000a65c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TXSWPW7
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TXSWPW7
Bits
Name Type Reset Description
31:0 TXSWPW7 R/W 32’h0 IRTX Software Mode pulse width data #56 #63, each pulse
is represented by 4-bit
([3:0] is the 1st pulse, [7:4] is the 2nd pulse, [11:8] is the 3rd
pulse, etc)
BL702/704/706 Reference Manual 173/ 375
