BL702/704/706 Reference Manual
8.4.19 irrx_data_word0
Address：0x4000a694
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RXDAW0
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RXDAW0
Bits
Name Type Reset Description
31:0 RXDAW0 R 32’h0 RX data word 0
8.4.20 irrx_data_word1
Address：0x4000a698
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RXDAW1
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RXDAW1
Bits
Name Type Reset Description
31:0 RXDAW1 R 32’h0 RX data word 1
8.4.21 irrx_swm_fifo_config_0
Address：0x4000a6c0
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD RXFIFOCN RXF
UF
RXF
OF
RSVD RXF
CLR
Bits
Name Type Reset Description
31:11 RSVD
10:4 RXFIFOCN R 7’d0 RX FIFO available count
3 RXFUF R 1’b0 Underflow flag of RX FIFO, can be cleared by rx_fifo_clr
BL702/704/706 Reference Manual 176/ 375
