BL702/704/706 Reference Manual
9.4.6 spi_rxd_ignr
Address：0x4000a218
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD RXDIGS
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD RXDIGP
Bits
Name Type Reset Description
31:21 RSVD
20:16 RXDIGS R/W 5’d0 Starting point of RX data ignore function
15:5 RSVD
4:0 RXDIGP R/W 5’d0 Stopping point of RX data ignore function
9.4.7 spi_sto_value
Address：0x4000a21c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD STOV
Bits
Name Type Reset Description
31:12 RSVD
11:0 STOV R/W 12’hFFF Time-out value for spi_sto_int triggering
9.4.8 spi_fifo_config_0
Address：0x4000a280
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD RFUF RFOF TFUF TFOF RFC TFC DMAR
EN
DMAT
EN
