BL702/704/706 Reference Manual
10.4.4 data_config
Address：0x4000a00c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD BIT
INV
Bits
Name Type Reset Description
31:1 RSVD
0 BITINV R/W 1’b0 Bit-inverse signal for each data byte
0: Each byte is sent out LSB-first
1: Each byte is sent out MSB-first
10.4.5 utx_ir_position
Address：0x4000a010
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TXIRPP
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TXIRPS
Bits
Name Type Reset Description
31:16 TXIRPP R/W 16’d159 STOP position of UART TX IR pulse
15:0 TXIRPS R/W 16’d112 START position of UART TX IR pulse
10.4.6 urx_ir_position
Address：0x4000a014
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RXIRPS
