BL702/704/706 Reference Manual
Bits
Name Type Reset Description
31:16 RSVD
15:0 RXIRPS R/W 16’d111 START position of UART RXD pulse recovered from IR sig-
nal
10.4.7 urx_rto_timer
Address：0x4000a018
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD RXRTOVA
Bits
Name Type Reset Description
31:8 RSVD
7:0 RXRTOVA R/W 8’d15 Time-out value for triggering RTO interrupt (unit: bit time)
10.4.8 uart_sw_mode
Address：0x4000a01c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD RRV RRM TTV TTM
Bits
Name Type Reset Description
31:4 RSVD
3 RRV R/W 1’b0 UART RX RTS output SW control value
2 RRM R/W 1’b0 UART RX RTS output SW control mode
1 TTV R/W 1’b0 UART TX TXD output SW control value
0 TTM R/W 1’b0 UART TX TXD output SW control mode
