12.4.22 pwm3_thre2
Address：0x4000a488
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
THRE2
Bits
Name Type Reset Description
31:16 RSVD
15:0 THRE2 R/W 16’d0 PWM sencond counter threshold, can’t be smaller that
pwm_thre1
12.4.23 pwm3_period
Address：0x4000a48c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
PERIOD
Bits
Name Type Reset Description
31:16 RSVD
15:0 PERIOD R/W 16’d0 PWM period setting
12.4.24 pwm3_config
Address：0x4000a490
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD STOP
STA
STOP
EN
SW
MODE
SW
FVAL
STOP
MODE
OUT
INV
CLKSEL
