BL702/704/706 Reference Manual
Bits
Name Type Reset Description
1 TIER21 R/W 1’b0 Timer2 match register 1 interrupt enable register
0 TIER20 R/W 1’b0 Timer2 match register 0 interrupt enable register
13.4.13 TIER3
Address：0x4000a548
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD TIER
32
TIER31 TIER30
Bits
Name Type Reset Description
31:3 RSVD
2 TIER32 R/W 1’b0 Timer3 match register 2 interrupt enable register
1 TIER31 R/W 1’b0 Timer3 match register 1 interrupt enable register
0 TIER30 R/W 1’b0 Timer3 match register 0 interrupt enable register
13.4.14 TPLVR2
Address：0x4000a550
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TPLVR2
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TPLVR2
Bits
Name Type Reset Description
31:0 TPLVR2 R/W 32’h0 Timer2 pre-load value register
