BL702/704/706 Reference Manual
13.4.15 TPLVR3
Address：0x4000a554
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
TPLVR3
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
TPLVR3
Bits
Name Type Reset Description
31:0 TPLVR3 R/W 32’h0 Timer3 pre-load value register
13.4.16 TPLCR2
Address：0x4000a55c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD TPLCR2
Bits
Name Type Reset Description
31:2 RSVD
1:0 TPLCR2 R/W 2’h0 Timer2 pre-load control register
2’d0 - No pre-load
2’d1 - Pre-load with match comparator 0
2’d2 - Pre-load with match comparator 1
2’d3 - Pre-load with match comparator 2
13.4.17 TPLCR3
Address：0x4000a560
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD TPLCR3
