BL702/704/706 Reference Manual
Bits
Name Type Reset Description
31:2 RSVD
1:0 TPLCR3 R/W 2’h0 Timer3 pre-load control register
2’d0 - No pre-load
2’d1 - Pre-load with match comparator 0
2’d2 - Pre-load with match comparator 1
2’d3 - Pre-load with match comparator 2
13.4.18 WMER
Address：0x4000a564
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD WRIE WE
Bits
Name Type Reset Description
31:2 RSVD
1 WRIE R/W 1’b0 WDT reset/interrupt mode register
1’b0 - WDT expiration to generate interrupt
1’b1 - WDT expiration to generate reset source
0 WE R/W 1’b0 WDT enable register
13.4.19 WMR
Address：0x4000a568
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
WMR
Bits
Name Type Reset Description
31:16 RSVD
15:0 WMR R/W 16’hffff WDT counter match value register
