13.4.22 TICR2
Address：0x4000a578
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD TCLR
22
TCLR
21
TCLR
20
Bits
Name Type Reset Description
31:3 RSVD
2 TCLR22 W 1’b0 Timer2 Interrupt clear for match comparator 2
1 TCLR21 W 1’b0 Timer2 Interrupt clear for match comparator 1
0 TCLR20 W 1’b0 Timer2 Interrupt clear for match comparator 0
13.4.23 TICR3
Address：0x4000a57c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD TCLR
32
TCLR
31
TCLR
30
Bits
Name Type Reset Description
31:3 RSVD
2 TCLR32 W 1’b0 Timer3 Interrupt clear for match comparator 2
1 TCLR31 W 1’b0 Timer3 Interrupt clear for match comparator 1
0 TCLR30 W 1’b0 Timer3 Interrupt clear for match comparator 0
