BL702/704/706 Reference Manual
Name
Description
TXCTRL TX control
17.8.1 MODE
Address：0x4000d000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD RMII
EN
RECS
MALL
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
PAD HUG
EN
CRC
EN
RSVD FULL
D
RSVD IFG PRO RSVD BRO NO
PRE
TXEN RXEN
Bits
Name Type Reset Description
31:18 RSVD
17 RMIIEN R/W 1’b0 RMII mode enable
0: MII PHY I/F is used
1: RMII PHY I/F is used
16 RECSMALL R/W 1’b0 Receive small frame enable
0: Frames smaller than MINFL are ignored.
1: Frames smaller than MINFL are accepted.
15 PAD R/W 1’b1 Padding enable
0: Do not add pads to frames shorter than MINFL.
1: Add pads to short frames, until the length equals MINFL.
14 HUGEN R/W 1’b0 Huge frames enable
0: The maximum frame length is MAXFL. All additional
bytes are dropped.
1: Frame size is not limited by MAXFL and can be up to
64K bytes.
13 CRCEN R/W 1’b1 CRC Enable
0: TX MAC does not append CRC field.
1: TX MAC will append CRC field to every frame.
12:11 RSVD
10 FULLD R/W 1’b0 Full duplex
0: Half duplex mode.
1: Full duplex mode.
9:7 RSVD
