BL702/704/706 Reference Manual
17.8.9 MIICOMMAND
Address：0x4000d02c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD WCTR
DATA
RSTA SCAS
Bits
Name Type Reset Description
31:3 RSVD
2 WCTRDATA R/W 1’b0 Write control data, setting this bit to 1 will trigger the com-
mand (auto cleared)
Note: [2]/[1]/[0] cannot be asserted at the same time, exe-
cute one command at a time
1 RSTA R/W 1’b0 Read status, setting this bit to 1 will trigger the command
(auto cleared)
Note: [2]/[1]/[0] cannot be asserted at the same time, exe-
cute one command at a time
0 SCAS R/W 1’b0 Scan status, setting this bit to 1 will trigger the command
(auto cleared)
Note: [2]/[1]/[0] cannot be asserted at the same time, exe-
cute one command at a time
17.8.10 MIIADDRESS
Address：0x4000d030
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD RGAD RSVD FIAD
Bits
Name Type Reset Description
31:13 RSVD
12:8 RGAD R/W 5’h0 Register Address
7:5 RSVD
4:0 FIAD R/W 5’h0 PHY Address
