BL702/704/706 Reference Manual
Bits
Name Type Reset Description
14 EP3CIT R 1’b0 EP3 IN or OUT command is received
13 EP2DIT R 1’b0 EP2 IN or OUT command is finished
12 EP2CIT R 1’b0 EP2 IN or OUT command is received
11 EP1DIT R 1’b0 EP1 IN or OUT command is finished
10 EP1CIT R 1’b0 EP1 IN or OUT command is received
9 EP0DIT R 1’b0 EP0 OUT command is finished
8 E0OCIT R 1’b0 EP0 OUT command is received
7 E0IDIT R 1’b0 EP0 IN command is finished
6 E0ICIT R 1’b0 EP0 IN command is received
5 E0SDIT R 1’b0 EP0 SETUP command is finished
4 E0SCIT R 1’b0 EP0 SETUP command is received
3 GDCIT R 1’b0 GET_DESCRIPTOR command is received
2 VTIT R 1’b0 VBUS detection is toggled, check 0x1FC[31] for vbus_de-
tect status
1 URIT R 1’b0 USB reset is triggered
0 SIT R 1’b0 SOF is received
18.4.8 usb_int_mask
Address：0x4000d828
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
UEM S3M LPM LWM RDM RSVD E7DM E7CM E6DM E6CM E5DM E5CM E4DM E4CM
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
E3DM E3CM E2DM E2CM E1DM E1CM E0
ODM
E0
OCM
E0
IDM
E0
ICM
E0
SDM
E0
SCM
GDCM VTM URM SM
Bits
Name Type Reset Description
31 UEM R/W 1’b1 Interrupt mask of usb_err_int
30 S3M R/W 1’b1 Interrupt mask of sof_3ms_int
29 LPM R/W 1’b1 Interrupt mask of lpm_pkt_int
28 LWM R/W 1’b1 Interrupt mask of lpm_wkup_int
27 RDM R/W 1’b1 Interrupt mask of usb_rend_int
26:24 RSVD
BL702/704/706 Reference Manual 323/ 375
@2021 Bouffalo Lab
