BL702/704/706 Reference Manual
Bits
Name Type Reset Description
23 E7DM R/W 1’b1 Interrupt mask of ep7_done_int
22 E7CM R/W 1’b1 Interrupt mask of ep7_cmd_int
21 E6DM R/W 1’b1 Interrupt mask of ep6_done_int
20 E6CM R/W 1’b1 Interrupt mask of ep6_cmd_int
19 E5DM R/W 1’b1 Interrupt mask of ep5_done_int
18 E5CM R/W 1’b1 Interrupt mask of ep5_cmd_int
17 E4DM R/W 1’b1 Interrupt mask of ep4_done_int
16 E4CM R/W 1’b1 Interrupt mask of ep4_cmd_int
15 E3DM R/W 1’b1 Interrupt mask of ep3_done_int
14 E3CM R/W 1’b1 Interrupt mask of ep3_cmd_int
13 E2DM R/W 1’b1 Interrupt mask of ep2_done_int
12 E2CM R/W 1’b1 Interrupt mask of ep2_cmd_int
11 E1DM R/W 1’b1 Interrupt mask of ep1_done_int
10 E1CM R/W 1’b1 Interrupt mask of ep1_cmd_int
9 E0ODM R/W 1’b1 Interrupt mask of ep0_out_done_int
8 E0OCM R/W 1’b1 Interrupt mask of ep0_out_cmd_int
7 E0IDM R/W 1’b1 Interrupt mask of ep0_in_done_int
6 E0ICM R/W 1’b1 Interrupt mask of ep0_in_cmd_int
5 E0SDM R/W 1’b1 Interrupt mask of ep0_setup_done_int
4 E0SCM R/W 1’b1 Interrupt mask of ep0_setup_cmd_int
3 GDCM R/W 1’b1 Interrupt mask of get_dct_cmd_int
2 VTM R/W 1’b1 Interrupt mask of vbus_tgl_int
1 URM R/W 1’b1 Interrupt mask of usb_reset_int
0 SM R/W 1’b1 Interrupt mask of sof_int
18.4.9 usb_int_clear
Address：0x4000d82c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
UEC S3C LPC LWC RDC RSVD E7DC E7CC E6DC E6CC E5DC E5CC E4DC E4CC
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
E3DC E3CC E2DC E2CC E1DC E1CC E0
ODC
E0
OCC
E0
IDC
E0
ICC
E0
SDC
E0
SCC
GDCC VTC URC E0
