19.4.7 HBN_IRQ_STAT
Address：0x4000f018
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
IRQSTATE
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
IRQSTATE
Bits
Name Type Reset Description
31:0 IRQSTATE R 0 [22] acomp1
[20] acomp0
[18] brown-out
[17] irq_pir state
[16] irq_rtc state
[4:0] hbn_pin_wakeup state (GPIO13 GPIO9)
19.4.8 HBN_IRQ_CLR
Address：0x4000f01c
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
IRQCLR
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
IRQCLR
Bits
Name Type Reset Description
31:0 IRQCLR W 0 [22] irq_acomp1 clear
[20] irq_acomp0 clear
[18] irq_bor clear
[17] irq_pir clear
[16] irq_rtc clear
[4:0] hbn_pin_wakeup clear (GPIO13 GPIO9)
