BL702/704/706 Reference Manual
Bits
Name Type Reset Description
1 RSVD
0 WKIT R 0 PDS Wakeup Interrupt
19.5.4 PDS_CTL2
Address：0x4000e010
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD FUSB
GCLK
FBZ
GCLK
RSVD FNP
GCLK
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
FUSB
MSLP
FBZ
MSLP
RSVD FNP
MSLP
FUSB
RST
FBZP
RST
RSVD FNP
PRST
FUSB
ISEN
FBZ
ISEN
RSVD FNP
ISEN
FUSB
PWOF
FBZ
PWOF
RSVD FNP
PWOF
Bits
Name Type Reset Description
31:20 RSVD
19 FUSBGCLK R/W 0 manual force USB clock gated
18 FBZGCLK R/W 0 manual force BZ clock gated
17 RSVD
16 FNPGCLK R/W 0 manual force NP clock gated
15 FUSBMSLP R/W 0 manual force USB memory sleep
14 FBZMSLP R/W 0 manual force BZ memory sleep
13 RSVD
12 FNPMSLP R/W 0 manual force NP memory sleep
11 FUSBRST R/W 0 manual force USB pds reset
10 FBZPRST R/W 0 manual force BZ pds reset
9 RSVD
8 FNPPRST R/W 0 manual force NP pds reset
7 FUSBISEN R/W 0 manual force USB isolation
6 FBZISEN R/W 0 manual force BZ isolation
5 RSVD
4 FNPISEN R/W 0 manual force NP isolation
3 FUSBPWOF R/W 0 manual force USB power off
2 FBZPWOF R/W 0 manual force BZ power off
