BL702/704/706 Reference Manual
Bits
Name Type Reset Description
1 RSVD
0 FNPPWOF R/W 0 manual force NP power off
19.5.5 PDS_CTL3
Address：0x4000e014
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD MSIS USB
ISO
BLE
ISO
BZ
ISO
RSVD NP
ISO
RSVD
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RSVD FBLE
GCLK
FMIS
GCLK
RSVD FBLE
MSTB
FMIS
MSTB
RSVD FBLE
PRST
FMIS
PRST
RSVD FBLE
ISO
RSVD FBLE
PWOF
FMIS
PWOF
RSVD
Bits
Name Type Reset Description
31 RSVD
30 MSIS R/W 1 1 : make misc isolated at PDS Sleep state
0 : make misc isolated at PDS Sleep state
29 USBISO R/W 1 1 : make usb isolated at PDS Sleep state
0 : make usb isolated at PDS Sleep state
28 BLEISO R/W 1 1 : make bz_Ble isolated at PDS Sleep state
0 : make bz_Ble isolated at PDS Sleep state
27 BZISO R/W 1 1 : make BZ isolated at PDS Sleep state
0 : make BZ isolated at PDS Sleep state
26:25 RSVD
24 NPISO R/W 1 1 : make NP isolated at PDS Sleep state
0 : make NP isolated at PDS Sleep state
23:15 RSVD
14 FBLEGCLK R/W 0 manual force BZ_BLE gate_clk
13 FMISGCLK R/W 0 manual force MISC gate_clk
12 RSVD
11 FBLEMSTB R/W 0 manual force BZ_BLE mem_stby
10 FMISMSTB R/W 0 manual force MISC mem_stby
9 RSVD
8 FBLEPRST R/W 0 manual force BZ_BLE pds_rst
7 FMISPRST R/W 0 manual force MISC pds_rst
