BradyPrinter S3100 Sign & Label Printer User’s Manual 7
Unpacking and Setting up Printer
System Components
System Components
Figure 2-1. Printer Components
Note: The printer is equipped with a universal power supply and can be operated
with a supply voltage of 100 to 240 V~, 50- to 60 Hz. The printer senses the voltage
type and automatically adjusts for the power source.
1 Display (with touchscreen) 2 Sleep/Wake Button
3 Enclosure Cover 4 Label Exit
5 Media Wiper 6 Media Guides
7Media 8Cutter
9 Ribbon Cartridge 10 Ribbon Cover
11 USB Port, Ethernet Port,
Power Switch, and Power
Cord Connector
12 Keyboard
