BradyPrinter S3100 Sign & Label Printer User’s Manual 86
Cleaning the Printer
Cleaning the Sensors
Cleaning the Sensors
The media and cutter sensors are located inside the printer and may be covered
with dust that results from cutting the media. The media sensor is located under
the yellow media guide. The cutter sensor is located above the cutting blade and
is visible only when the cutter is released.
Materials Required
• BradyPrinter S3100 Cleaning Kit (Cat # B31-CCT)
• Isopropyl Alcohol
To clean the sensors:
1. If necessary, remove power and media from the printer (see “Removing
Power and Media from Printer” on page 81).
2. If not already released, squeeze the two yellow cutter tabs to release the
cutter.
3. With a pre-moistened foam swab, gently wipe the surface of the media
sensor [10] and cutter sensor [11] at the locations shown in the figure. Do not
allow the alcohol to drip from the swab.
10
11

Brady BradyPrinter S3100 Specifications

General

Print Technology	Thermal Transfer
Resolution	300 dpi
Application	Industrial Labeling
Max Print Width	4 inches
Connectivity	USB, Ethernet
Display	Color touchscreen
Power Supply	100-240V AC, 50/60Hz
