BradyPrinter S3100 Sign & Label Printer User’s Manual 33
Set Label Attributes
Label Width
Label Width
You can adjust the width of the installed media to accommodate up to 4 labels
printed in the space of the adjusted width. Adjusting the width automatically
changes the size of the font and the margins. In this function, label width also
addresses the height of the label, measured from top to bottom. For instance, if
using 4-inch tape, when you select 2 Up, two labels would be stacked and printed
on the tape, each taking up 2 inches. If you select 3 Up, three labels would be
stacked and printed on the tape, each taking up approximately 1.333 inches. The
fourth label would be printed trailing the first label.
Figure: Stacking labels using 2-, 3-, or 4-Up label width
To adjust the width:
1. Touch the Menu button.
2. Under Label, touch the Size & Orientation button.
3. Under Label Width, touch the Set Label Width button.
Match media size Label width - 2 UP Label width - 3 UP Label width - 4 UP

Brady BradyPrinter S3100 Specifications

General

Print Technology	Thermal Transfer
Resolution	300 dpi
Application	Industrial Labeling
Max Print Width	4 inches
Connectivity	USB, Ethernet
Display	Color touchscreen
Power Supply	100-240V AC, 50/60Hz
