9.2 Head Joint Rubber, Head/carriage Unit and CR Timing Belt

(1) Plug the Power cord into an electrical outlet.

Fig. 3-1

(2) Switch the machine to the maintenance mode and press the

Mono Start

, and

keys in this order to automatically move the Head/carriage unit to the position shown

in the figure.

(3) Pull out the Power cord from the electrical outlet.

(4) Open the Scanner cover.

Fig. 3-2

Power cord

Panel ASSY

Power cord

Machine body

Power switch

Head/carriage unit

Scanner cover
