3-45

Confidential

9.5 Manual Feed Slot Cover ASSY

(1) Release the four Pins and remove the Manual feed slot cover ASSY from the

Document scanner unit.

Fig. 3-31

Pin

Pin

Pin

Pin

Manual feed slot cover ASSY

Document scanner unit
