9.21 First Side CIS Unit

(1) Turn the Document scanner base ASSY upside down.

(2) Remove the five screws (TAPTITE CUP B M3x10) from the Document scanner

base ASSY.

Assembling Note: When tightening the five screws (TAPTITE CUP B M3x10), tighten

them in the order shown in the figure.

Fig. 3-70

TAPTITE CUP

TAPTITE CUP B M3x10

Document scanner base ASSY

B M3x10
