Brother MFC-J6520DW Service Manual

1-4
Confidential
2FAX
3 PRINTER
4COPY
Model All models
Modem Speed (bps)
33,600 (FAX)
Transmission Speed
Approx. 3 sec (ITU-T Test Chart #1, MMR)
ITU-T Group
Super G3
COLOR FAX
Document
(Send/Receive)
Yes/Yes (ITU-T color FAX)
Memory
(Send/Receive)
No/No (ITU-T color FAX)
Model All models
Print Speed ESAT
(mono/color)
(based on ISO/IEC 24734)
22/20 ipm
Draft Print Speed
(mono/color)
* time calculated including
paper feeding
35/27 ppm
Resolution
(horizontal x vertical)
Up to 1,200 x 6,000 dpi
Auto Duplex Print Yes (Up to A3/LGR)
Model All models
COPY SPEED ESAT
(mono/color)
(based on ISO/IEC 24735)
12/9 ipm
COPY SPEED FCOT
(based on ISO/
IEC 24735 Annex D)
18 sec
Resolution
(horizontal x
vertical)
Mono
Print: Max. 1,200 x 2,400 dpi
Scan: Max. 1,200 x 2,400 dpi
Color
Print: Max. 1,200 x 2,400 dpi
Scan: Max. 1,200 x 1,200 dpi
Duplex Copy Yes

Brother MFC-J6520DW Specifications

General

Type	all in one
Color	gray
Tray Capacity	250
Automatic Document Feeder Capacity	35 sheets
Paper Size	11" x 17"
Paper Handling	up to 250 sheets
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
Print Resolution Mono	up to 6000 x 1200
Print Resolution Color	up to 6000 x 1200
Maximum Number of Pages Per Month	up to 25, 000
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Copier Resolution Mono	up to 2400 x 1200
Copier Resolution Color	up to 2400 x 1200
Fax Function	yes
Cartridges	lc103bk/c/m/y
Number Of Cartridges	4
Internal Memory	yes
Memory Card	yes
Network	wired, wireless
Connectivity	usb
OS Compatibility	pc: windows xp home, xp professional, vista, 7, 8, server 2003, server 2003 r2, server 2008, server 2008 r2 or server 2012, mac: os x 10.6.x, 10.7.x or 10.8.x
Mobile Devices Connection	yes

Weight and Dimensions

Height	21.8 inches
Width	17 inches
Net Weight	31.5 pounds
