Brother MFC-J6520DW Service Manual

1-6
Confidential
8 SUPPLIES/OPTIONS
9 SERVICE INFORMATION
Model MFC-J3520/J3720/J6520DW/J6720DW/J6920DW MFC-J6925DW
Ink
Cartridge
Yield @
ISO
pattern
(Pages)
Bundled Cartridges
BK: 390
CL: 390
BK: 2160
CL: 540
Supply High Yield
Cartridges
BK: 600
CL: 600
(Except for MFC-J3520/3720 for China)
N/A
Supply Super High
Yield Cartridges
BK: 2,400
CL: 1,200
Storage Condition of Ink
Cartridge
(Temperature) Normal condition: -20 to 40°C
(Humidity) Normal condition: 20 to 80%
* Storage condition at the temperature of 40 to 50°C and the humidity of 80 to 95%:
Up to 5 days
* Storage condition at the temperature of 40 to 60°C and the humidity of Non controll condition:
Up to 5 days
Model All models
Monthly Volume 26,000 pages
Machine Life 60,000 pages or 5 years
MTBF
(Mean Time Between Failures)
4,000 hours
MTTR
(Mean Time To Be Repaired)
30 minutes

Brother MFC-J6520DW Specifications

General

Type	all in one
Color	gray
Tray Capacity	250
Automatic Document Feeder Capacity	35 sheets
Paper Size	11" x 17"
Paper Handling	up to 250 sheets
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
Print Resolution Mono	up to 6000 x 1200
Print Resolution Color	up to 6000 x 1200
Maximum Number of Pages Per Month	up to 25, 000
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Copier Resolution Mono	up to 2400 x 1200
Copier Resolution Color	up to 2400 x 1200
Fax Function	yes
Cartridges	lc103bk/c/m/y
Number Of Cartridges	4
Internal Memory	yes
Memory Card	yes
Network	wired, wireless
Connectivity	usb
OS Compatibility	pc: windows xp home, xp professional, vista, 7, 8, server 2003, server 2003 r2, server 2008, server 2008 r2 or server 2012, mac: os x 10.6.x, 10.7.x or 10.8.x
Mobile Devices Connection	yes

Weight and Dimensions

Height	21.8 inches
Width	17 inches
Net Weight	31.5 pounds
