9.41 Jam Clear Cover

(1) Remove the four screws (TAPTITE BIND B M4x12) and take out the Lower cover

from the Lower tray unit.

Fig. 3-107

TAPTITE BIND

B M4x12

TAPTITE BIND B M4x12

TAPTITE

BIND

B M4x12

Lower cover

Lower tray unit
