9.42 T1 Bank ASSY

(1) Slightly warp the Inside cover ASSY to release the Bosses and remove the ASSY.

(2) Release the three Hooks on the bottom of the T1 bank ASSY and remove them in

the direction of arrow.

Fig. 3-109

Boss

Hook

T1 bank ASSY

Hook

Lower cover

Inside cover ASSY
